Magewell USB Capture HDMI Gen 2, USB2.0/3.0 DONGLE

Cijena
3.749 kn ~ 501 €
Šifra oglasa: 35720172

Osnovne informacije

Lokacija
Grad Zagreb, Maksimir, Lašćina
Stanje
novo
Mogućnost dostave
Dostava moguća
Raspoloživost
Moguća narudžba
Interna šifra
44552

Opis oglasa

Novo zapakirano, capture card.

Jamstvo : 24 mj.


Opis/specifikacija:

SUPPORTED OS
- Windows 7/8/8.1/10/Server 2008/Server 2008 R2/Server 2012/Server 2016 (x86 & x64)
- Linux (support x86, x64 & ARM architecture)
* Ubuntu 12.04/14.04/16.04/17.04/17.10 (x86 & x64)
* CentOS 6.5/7 (x86 & x64)
* Fedora 25/26/27 (x86 & x64)
* Red hat 6.5 and above (x86 & x64)
* Other Linux OS with kernel version 2.6.35 and above
- Mac:
* OS X 10.9/10.10/10.11
* macOS 10.12/10.13
- Chrome OS

RECOMMENDED OS (TESTED)
- Windows 7 Ultimate/8.1 Enterprise/10 Enterprise/Server 2008 R2 DataCenter/Server 2012 R2 DataCenter/Server 2016 R2 DataCenter (x86 & x64)
- Linux:
* Ubuntu 12.04/14.04/16.04 (x86 & x64)
* Ubuntu 17.04/17.10 (x64)
* CentOS 6.5/7.2 (x86 & x64)
* Fedora 25/26 (x64)
* Red hat 6.5 (x86 & x64)
- Mac:
* OS X 10.9.5/10.10/10.11.2/10.11.3/10.11.4
* macOS 10.12/10.13.2/10.13.3

SUPPORTED APIs
- Windows:
* DirectShow
* Wave API/DirectSound/WASAPI
- Linux:
* V4L2
* ALSA
- OS X/macOS:
* QuickTime
* AV Foundation

SUPPORTED SOFTWARE
- VLC
- VirtualDub
- OBS
- XSplit
- vMix
- VidBlaster
- Wirecast
- Microsoft Media Encoder
- Adobe Flash Media Encoder
- Any other DirectShow, V4L2, QuickTime, AV Foundation based encoding or streaming software

INPUT INTERFACES
- HDMI
* DVI-D 1.0
* HDMI 1.4a

HOST INTERFACE
- USB 3.0
* compatible with USB 2.0
* compatible with USB 3.1 Gen 1

INPUT FEATURES
- Support for input video resolutions up to 2048×2160

HDMI SPECIFIC FEATURES
- 165MHz HDMI receiver
- Adaptive HDMI equalizer support for cables lengths up to 30M
- Support for customized EDID
- Support for extraction of AVI/Audio/SPD/MS/VS/ACP/ISRC1/ISRC2/Gamut InfoFrames
- Full colorimetry support
- Support for 8/10/12-bit color depth
- Support for RGB 4:4:4,YCbCr 4:4:4,YCbCr 4:2:2 color sampling
- Support for 2 channel IEC60958 audio streams
- Support for extraction of audio formation information & channel status data
- Support for extraction of video timing information
- Support for extraction of 3D format information
- Support for Side-by-Side Half, Top-and-Bottom, Frame Packing 3D mode

VIDEO CAPTURE FORMAT
- Support for capture resolutions up to 2048×2160
- Support for capture frame rates up to 120fps (Actual capture frame rate can be limited by the USB bandwidth and internal working frequency - Typical capture frame rates on the Intel USB3.0 controller are as follows)
* 1920×1080 YUY2 (up to 75fps)
* 1920×1080 RGB24 (up to 60fps)
- Support for YUY2 & UYVY 4:2:2 8-bit
- Support for RGB24 & RGB32 4:4:4 8-bit
- The default capture format is YUY2. More capture formats can be set using USB Capture Utility

VIDEO PROCESSING FEATURES
- Video processing pipelines with 160 Mpixels/s processing bandwidth
- Video cropping
- Video scaling
- Video de-interlacing
* Weave
* Blend top & bottom field
* Top field only
* Bottom field only
- Video aspect ratio conversion
* Auto or manual selection of input aspect ratio
* Auto or manual selection of capture aspect ratio
* Three aspect ratio conversion modes: Ignore (Anamorphic), Cropping or Padding (Letterbox or Pillarbox)
- Video color format conversion
* Auto or manual selection of input color format & quantization range
* Auto or manual selection of capture color format, quantization range & saturation range
* Support for RGB, YCbCr 601, YCbCr 709 color formats
* Support for Limited or Full quantization range
* Support for Limited, Full & "Extended gamut" saturation range
- Video frame rate conversion
- Vertical flip and mirror

MULTIPLE DEVICES ON ONE COMPUTER
- Support for connecting multiple USB devices to one system
- Support for setting the device serial number as the device name shown in the system using USB Capture Utility

SDK
- The USB Capture SDK provide functions including signal status extraction, capture configuration, etc.

FIRMWARE UPGRADE
- Multiple devices in one system can be upgraded simultaneously

LED INDICATOR
- Status LEDs indicate the working state of each channel:
* Pulsing slowly: idle
* On: input signal locked
* Off: input signal unlocked
* Double blinks: memory failed or FPGA configuration failed

FORM FACTOR
- 92.2(L) × 40.2(W) × 12.3(H) mm

ACCESSORIES
- USB 3.0 cable

POWER CONSUMPTION
- 5V max current: 0.5 A
- max power consumption: 2.5 W

WORKING ENVIRONMENT
- Operating temperature: 0C to 50 deg C
- Storage temperature: -20C to 70 deg C
- Relative Humidity: 5% to 90% non-condensing


*PDV u cijeni proizvoda.

-----------------------------------------------------------------------------------


Zatražite svoju ponudu, molim navedite slijedeće informacije:
- naziv privatne osobe ili naziv poslovnog subjekta
- adresa kupca
- telefon / mobitel za kontakt
- e-mail za slanje ponude


NAČINI PLAĆANJA:

KARTICE: BEZ KAMATA i naknada!
Načini plaćanja (jednokratno):
(na samoj dostavi kod vas ili putem internet linka po ponudi!)
Diners
Maestro
Mastercard
Mastercard Electronic
Visa
VIsa Electron
V Pay

Načini plaćanja (rate): BEZ KAMATA i naknada!
ZABA Mastercard: 2-36 rata
ZABA Visa AM: 2-36 rata
ZABA Visa Business: 2-36 rata
ZABA Maestro: 2-12 rata
PBZ Visa Premium: 2 - 12 rata
DINERS: 2 - 36 rata
RBA: 2-12 rata

Ostali načini plaćanja uz EKS:
VISA PBZ Premium potrošački kredit (13 - 60 rata)
VISA PBZ Business Premium potrošački kredit (13 - 24 rate poslovne kartice)
DINERS potrošački kredit (13 - 60 rata)

OSTALE JEDNOKRATNE TRANSAKCIJE:
- virman
- gotovina

*Unatoč svim naporima ne možemo 100% garantirati navedene cijene budući da su iste podložne promjenama. Za potvrdu navedene cijene molimo zatražite ponudu.
