Magewell Pro capture HDMI 4K Plus LT, LP PCIe x4, 1-channel HDMI

Cijena
1.226,23 € / 9.239 kn
Fiksni tečaj konverzije 1 € = 7,53450 kn
Šifra oglasa: 35660881

Osnovne informacije

Lokacija
Grad Zagreb, Maksimir, Lašćina
Stanje
novo
Interna šifra
44540

Opis oglasa

Novo zapakirano, capture card.


Opis/specifikacija:

SUPPORTED OS
- Windows 7/8/8.1/10/Server 2008/Server 2008 R2/Server 2012/Server 2016 (x86 & x64)
- Linux (support x86, x64 & ARM architecture)
* Ubuntu 12.04/14.04/16.04/17.04/17.10 (x86 & x64)
* CentOS 6.5/7 (x86 & x64)
* Fedora 25/26/27 (x86 & x64)
* Red hat 6.5 and above (x86 & x64)
* Other Linux OS with kernel version 2.6.35 and above
- Mac
* OS X 10.9/10.10/10.11
* macOS 10.12/10.13

RECOMMENDED OS (TESTED)
- Windows 7 Ultimate/8.1 Enterprise/10 Enterprise/Server 2008 R2 DataCenter/Server 2012 R2 DataCenter/Server 2016 R2 DataCenter (x86 & x64)
- Linux
* Ubuntu 12.04/14.04/16.04 (x86 & x64)
* Ubuntu 17.04/17.10 (x64)
* CentOS 6.5/7.2 (x86 & x64)
* Fedora 25/26 (x64)
* Red hat 6.5 (x86 & x64)
- Mac
* OS X 10.9.5/10.10/10.11.2/10.11.3/10.11.4
* macOS 10.12/10.13.2/10.13.3

SUPPORTED APIs
- Windows
* DirectShow
* DirectKS
* Wave API/DirectSound/WASAPI
- Linux
* V4L2
* ALSA

SUPPORTED SOFTWARE
- VLC
- VirtualDub
-OBS
- XSplit
- vMix
- VidBlaster
- Wirecast
- Microsoft Media Encoder
- Adobe Flash Media Encoder
- Any other DirectShow/V4L2 encoding/streaming software

INPUT INTERFACES
- HDMI
* HDMI 2.0

HOST INTERFACE
- PCIe Gen2 x4

LOOP-THROUGH INTEFACE
- HDMI
* HDMI 2.0

INPUT FEATURES
- Support for input video resolutions up to 4096×2160 pixels

HDMI SPECIFIC FEATURES
- 594MHz HDMI receiver
- Adaptive HDMI equalizer
- Support for customized EDID
- Support for extraction of AVI/Audio/SPD/MS/VS/ACP/ISRC1/ISRC2/Gamut/HDR/VBI InfoFrames
- Full colorimetry support
- Support for 8/10/12-bit color depths
- Support for RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 color sampling
- Support for up to 8-channel IEC60958/IEC61937 audio streams
- Support for extraction of audio formation information & channel status data
- Support for extraction of video timing information
- Support for extraction of 3D format information
- Support for extraction of Sony/Canon DSLR time code
- Support for Side-by-Side Half, Top-and-Bottom, Frame Packing 3D mode.
- Support for HDR10

VIDEO CAPTURE FORMATS
- Support for capture image resolutions up to 4096×2160 pixels
- Support for capture frame rates up to 144fps (Actual capture frame rate can be limited by PCIe bandwidth & image resolution)
- Support for 4:2:0 8-bit capture formats: NV12, I420, YV12
- Support for 4:2:2 8-bit capture formats: YUY2, YUYV, UYVY
- Support for 4:4:4 8-bit capture formats: V308, IYU2, V408, BGR24, BGR32
- Support for 4:4:4 10-bit capture formats: V410, Y410
- More capture formats are supported via Magewell Capture SDK for DirectKS

VIDEO PROCESSING FEATURES
- Two video processing pipelines with 720Mpixels/s processing bandwidth for each one
- Full 10-bit video processing
- Video cropping- Video scaling
- Video de-interlacing
* Weave
* Blend top & bottom field
* Top field only
* Bottom field only
- Video aspect ratio conversion
* Auto or manual selection of input aspect ratio
* Auto or manual selection of capture aspect ratio
* Three aspect ratio conversion modes: Ignore (Anamorphic), Cropping or Padding (Letterbox or Pillarbox)
- Video color format conversion
* Auto or manual selection of input color format & quantization range
* Auto or manual selection of capture color format, quantization range & saturation range
* Support for RGB, YCbCr 601, YCbCr 709, YCbCr 2020 color formats
* Support for Limited or Full quantization range
* Support for Limited, Full & ‘Extended gamut’ saturation range
- Video frame rate conversion
- Video OSD composition
* Support for PNG OSD image (up to 4096x2160)
* Support for dynamic loading of RGBA OSD image via SDK

MULTIPLE CARDS PER SYSTEM
- Support for multiple cards plugged to one system
- On-board rotary switch to set card number, with 16 positions from 0 to F
- System hardware device tree will display "01: Pro Capture HDMI 4K+ LT" when rotary switch is set to 1, and so on
- The video and audio device names displayed in your software will include the card number (set by the rotary switch)

MULTIPLE CAPTURE STREAMS
- Unlimited capture streams for any one input channel
- Independent cropping, aspect ratio, color format, resolution, frame rate, de-interlacing and color adjustment settings for each individual stream

ULTRA LOW LATENCY SUPPORT
- Latency of 64 video lines
- Partial notification mode in SDK

TIMESTAMP & A/V SYNCHRONIZATION
- Hardware based 100ns high resolution clock
- Audio frames (192 audio samples) & video frames are stamped with hardware clock
- Hardware clock can be synchronized across cards (via SDK)

VIDEO CAPTURE SG-DMA
- 1600MB/s per channel DMA bandwidth in PCIe 2.x system
- 800MB/s per channel DMA bandwidth in PCIe 1.x system
- Support for auto detection of Intel tiled GPU surface
- Support for DirectGMA for AMD video adapter chipsets
- Support for GPUDirect for Nvidia video adapter chipsets

SDk
- Magewell Capture SDK for DirectShow for easy integration (Windows)
- Magewell Capture SDK for DirectKS for maximum flexibility & performance (Windows)

WINDOWS DRIVER TWEAKS
- All options can be controlled by three levels of registry key: global level, product level and device level
- Video, Audio, Crossbar filter names can be customized via registry keys

FIRMWARE UPGRADE
- Multiple cards in one system can be upgraded simultaneously
- Cards can be upgraded without a system power shutdown (In most cases, even a reboot is not needed)
- Safe upgrade
- If power off or system break down occur when the firmware is being upgraded, it will automatically restore to the initial version

LED INDOCATOR
- Status LEDs indicate the working state of each channel:
* Pulsing slowly: idle
* On: input signal locked
*- Off: input signal unlocked
* Double blinks: memory failed or FPGA configuration failed

FORM FACTOR
- Low profile PCIe x4 Add-on Card
- 140×68.88 mm (without PCI bracket)

POWER CONSUMPTION
- Max current at 12V: 0.48 A
- Max current at 3.3V: 0.82 A
- Max power consumption: 8.08 W

WORKING ENVIRONMENT
- Operating temperature: 0C to 40 deg C
- Storage temperature: -2C0 to 70 deg C
- Relative Humidity: 5% to 90% non-condensing

*PDV u cijeni proizvoda.

-----------------------------------------------------------------------------------


Zatražite svoju ponudu, molim navedite slijedeće informacije:
- naziv privatne osobe ili naziv poslovnog subjekta
- adresa kupca
- telefon / mobitel za kontakt
- e-mail za slanje ponude


NAČINI PLAĆANJA:

KARTICE: BEZ KAMATA i naknada!
Načini plaćanja (jednokratno):
(na samoj dostavi kod vas ili putem internet linka po ponudi!)
Diners
Maestro
Mastercard
Mastercard Electronic
Visa
VIsa Electron
V Pay

Načini plaćanja (rate): BEZ KAMATA i naknada!
ZABA Mastercard: 2-36 rata
ZABA Visa AM: 2-36 rata
ZABA Visa Business: 2-36 rata
ZABA Maestro: 2-12 rata
PBZ Visa Premium: 2 - 12 rata
DINERS: 2 - 36 rata
RBA: 2-12 rata

Ostali načini plaćanja uz EKS:
VISA PBZ Premium potrošački kredit (13 - 60 rata)
VISA PBZ Business Premium potrošački kredit (13 - 24 rate poslovne kartice)
DINERS potrošački kredit (13 - 60 rata)

OSTALE JEDNOKRATNE TRANSAKCIJE:
- virman
- gotovina

*Unatoč svim naporima ne možemo 100% garantirati navedene cijene budući da su iste podložne promjenama. Za potvrdu navedene cijene molimo zatražite ponudu.
