Cornet ED88T - uređaj za mjerenje elektromagnetskog zračenja

Uređaj za mjerenje elektromagnetskog zračenja Cornet ED88T.

Korisno ako imate baznu stanicu u blizini, vidi se i kako zrače razni uređaji npr. mobiteli, mikrovalne pećnice, pametni satovi, bežični miševi, tipkovnice, wifi routeri i sl.

FEATURES

Operation mode: Tri-mode of operation
                     - (RF mode):                High frequency RF Broadband
                     - (Gauss mode):           Low frequency Magnetic field
                     - (Electric Field mode): Low frequency Electric field
Frequency range & sensitivity:
                     - RF mode:       100MHz to 8.0GHz
                                              -60dBm to +5dBm, 14mv/m-26v/m,

                                              0.5uw/m-sq to 1.8 w/m-sq
                     - Gauss mode:  (1)50Hz to 10KHz
                                                  (0.1uT to 50uT)/ (1mG to 500mG)

                                              (2)50Hz to 1KHz
                                                  (0.01uT to 1uT)/ (0.1mG to 10mG)
                     - Electric field mode: 50Hz - 10KHz  (10v/m to 1000v/m)
Frequency Display:               100MHz to 2.7GHz

Signal :           Analog RF(AM/FM) and high speed digital burst

                      RF, GSM,TDMA,CDMA,PCS,Wi-Fi 2.4GH, 5.8GHz,
                      3.6GHz WiMAX, 3 - 6GHz Ultra-Wide-band, 3G, 4G , AC smart meter.
                      AC high voltage power line, Transformer, Motor, Appliance EMF.
Display mode:  dBm, mW/m2, V/m, uT, mGauss, MHz
Display:           Graphics LCD  multi-digit power level display, moving
                        Histogram, level  bar display, color LED segment.
 Function:        RF power level, LF magnetic field strength, Electric Field
                        strength, signal frequency, Hold, MAX, Peak Average,
                        Average, Sound output, audio Alarm, custom LED level

Upute za upotrebu
http://electrosmog.org/resources/ED-88Ta1UserManualQeng_Safe.pdf
