Technics SH-8055 Graphic Equalizer-radi kupnje drugoga ovaj ide

Sve šljaka na EQ,prodajem ga radi kupnje drugoga,nije u mint stanju sukladno godinama koja ogrebotina,ali ništa strašnog kaj bi mu naškodilo izgledu,cijena je fixna ne šaljem,ne natipkavam se ne odgovaram na poruke,ko je zainteresiran šibne u inbox kontakt br i ja zovem,zahvaljujem na razumjevanju.

• Manufacturer: Technics
• Model: SH-8055
• Type: Equalizer
• Years of manufacture: 1983 - 1989
• Colours: Silver, Black
• Power consumption: 17 W
• Dimensions (WxHxD): 430 x 108 x 272 mm
• Weight: 4,1 kg
• Original price approx.: 900 DM

Connections
• Number of inputs:
o Maximum input voltage: 8 V~
o Input impedance: 47 kOhm
o Microphone sensitivity: above -74 dBV/µ bar
o Microphone attenuation: -20 decibel
o Microphone connector (for the Real Time Spectrum Analyzer)
• Stereo Line IN and Line OUT (from and to the amplifier)
• Stereo Tape 1 Rec out and Play in
• Stereo Tape 2 Rec out and Play in
• Number of outputs:
o Line Out:

Specifications
• Frequency response: 5 Hz to 100 kHz
• Maximum output voltage: 8 V~
• Rated output voltage: 1 V~
• Nominal harmonic distortion: 0.002% at 1 kHz
• S/N ratio: 102 dB
• Channel separation: 70 dB
• Frequency response control: +12 dB to -12 dB
• Center frequencies: 25 Hz, 40 Hz, 63 Hz, 100 Hz, 160 Hz, 250 Hz, 500 Hz, 1 kHz, 2 kHz, 4 kHz, 8 kHz, 16 kHz
• Pink noise: 50 mV
• Display level control
• Display switch for each of the left and/or right channels
• Microphone attenuation switch
• Pink noise switch
• 3 input selector switches internally illuminated
• Rec Mode straight/ EQ
• EQ active/ deactive illuminated from inside
• 12 frequency controls each for left and right channel, illuminated with red LED

Special Features
• Front connection for measuring microphone (6.3 jack)
• Pink Noise
