ATC SCM 19 Active
- Cijena
- 4.500 €
Šifra oglasa: 42965030
Osnovne informacije
- Lokacija
- Grad Zagreb, Trnje, Vrbik
- Stanje
- rabljeno
Opis oglasa
SCM19A
New ATC designed and built dual suspension 25mm soft dome HF unit with precision alloy wave guide.
“SL” spec bass driver with 75mm integral Soft Dome.
9kg optimised short-coil/long gap motor assembly.
On-board grounded source 182 watt Class A/B Bi-amplifier.
Active crossover filters and overload protection.
Drivers: HF ATC 25mm dual suspension Tweeter, Mid/LF ATC 150mm SL
Matched Response: +/- 0.5dB
Frequency Response (-6dB): 54Hz-22kHz
Dispersion: ±80° Coherent Horizontal, ±10° Coherent Vertical
Max SPL: 108dB
Crossover Frequency: 2.5kHz
Input Connector: Female XLR
Input sensitivity: 1V
Filters: 2nd Order critically damped with phase compensation
Overload Protection: Active FET momentary gain reduction
Amplifier Output: 150W LF, 32W HF
Dimensions (HxWxD): 980 x 370 x 344mm / 38.58 x 14.56 x 13.54″ (inc. foot plinth & amp, spikes add 25mm to height, grill adds 34mm to depth)
Weight: 31kg
Spikes: 4 per cabinet, M8 x 1.25mm
New ATC designed and built dual suspension 25mm soft dome HF unit with precision alloy wave guide.
“SL” spec bass driver with 75mm integral Soft Dome.
9kg optimised short-coil/long gap motor assembly.
On-board grounded source 182 watt Class A/B Bi-amplifier.
Active crossover filters and overload protection.
Drivers: HF ATC 25mm dual suspension Tweeter, Mid/LF ATC 150mm SL
Matched Response: +/- 0.5dB
Frequency Response (-6dB): 54Hz-22kHz
Dispersion: ±80° Coherent Horizontal, ±10° Coherent Vertical
Max SPL: 108dB
Crossover Frequency: 2.5kHz
Input Connector: Female XLR
Input sensitivity: 1V
Filters: 2nd Order critically damped with phase compensation
Overload Protection: Active FET momentary gain reduction
Amplifier Output: 150W LF, 32W HF
Dimensions (HxWxD): 980 x 370 x 344mm / 38.58 x 14.56 x 13.54″ (inc. foot plinth & amp, spikes add 25mm to height, grill adds 34mm to depth)
Weight: 31kg
Spikes: 4 per cabinet, M8 x 1.25mm
