Sony Betamax Sl F 30ps

SpecificationsSystemVideo recording systemRotary two-head helical scanningVideo SignalCCIR standards, PAL and DDR SECAM colourAerial input75-ohm, asymmetrical aerial socketChannel coverageSL-F30EC SL-F30PSVHF: Western European channels E2-U20UHF: Western European channels E21-E68(Up to 30 programmes can be preset. )SL-F30EVHF: Western European channels E2-E12UHF: Western European channels E21-E68(Up to 12 programmes can be preset. )SL-F30UBUHF: European channels E21-E68(Up to 12 programmes can be preset. )RF output signalUHF channels E30 to E39 (variable)75 ohms, unbalancedVideoHorizontal resolution260 lines
B/W:300 linesVideo S/NColour: Better than 40dB
B/W: Better than 43dBAudio frequency response50Hz to 10,000HzAudio S/NBetter than 40dBInputs and outputsVideo inputVIDEO IN: BNC connector1.0 V (p-p)75 ohms, unbalanced, sync negativeVideo outputVIDEO OUT: BNC connector1.0 V (p-p)75Ohms, unbalanced, sync negativeAudio inputsAUDIO IN: phono jack47 kilohms, -10 dBs(0 d Bs = 0.775 V rms) Audio outputsAUDIO OUT: Phono jackLoad impedance less than 10 kilohms-10 dBs with 47 kilohms load, unbalancedTape transportTape speed18.73 mm/sec. Maximum recording time2 hours 10 min. (with Sony L-500 cassette)3 hours 15 min. (with L-750)Fast forward/rewind timeWithin 5 min. (with L-500)TimerClockCrystal lockTime indication24-hour cycleTimer setting Only for recording1 events/3 weeks, adjustable for any day or for all 7 days of the week or for every weekPower back-up3 mins at any one timeGeneralPower requirements240v AC, 50-60 HzPower consumption38WDimensionsApprox. 430 x 80 x 382 mm (w/h/d)(17 x 3 1/4 x 15 1/5 inches) including projecting parts and controlsWeightApprox. 8.2 kg (18 lbs 1 oz)
