Focusrite Saffire LE

Analog I/O
4 Analog Inputs:
2 x front panel XLR (mic) or 2 x front panel TRS Jacks (line/inst)
2 x rear panel TRS Jacks (line/inst)

Mic Gain: +13dB to + 60dB

Line 1&2 Gain: -10dB to +36dB

Instrument Gain: +13dB to +60dB

Line 3&4 Gain: +16dBu or +10dBV for full scale input (software switchable)

6 analog outputs

6 x rear panel TRS Jacks

Nominal output level 0dBFS = 16dBu, balanced

Front Panel Analog Volume control for outputs 1&2

Software Digital Volume control for outputs 3-6

All outputs are useable as monitoring outputs

DIGITAL I/O
2 x SPDIF (RCA phono) on rear panel (24-bit, 96kHz) Output transformer isolated

Clock Source: Internal clock or sync to word clock on SPDIF

MIDI I/O
1 in / 1 out on rear panel

FireWire S400
2 ports

Power
Either via FIREWIRE or external PSU (included)

Headphone Monitoring
1 x 1/4 in. TRS Jack on front panel (mirrors outputs 3-4)

High power headphone driver

Class-Leading Performance

Analog Performance - Inputs

Mic
Frequency Response: 20Hz - 20kHz +/- 0.1 dB

THD+N: 0.001% (measured at 1kHz with a 20Hz/22kHz bandpass filter)

Noise: EIN > 120dB (measured at 60dB of gain with 150 Ohm termination (20Hz/22kHz bandpass filter)

Line
Frequency Response: 20Hz - 20kHz +/- 0.1dB

THD+N: 0.001% (measured with 0dBFS input and 22Hz/22kHz bandpass filter)

Noise: -88dBu (22Hz/22kHz bandpass filter)

Instrument
Frequency Response: 20Hz - 20kHz +/- 0.1dB

THD+N: 0.004% (measured with 0dBu input and 20Hz/22kHz bandpass filter)

Noise: -87dBu (20Hz/22kHz bandpass filter)

Analog Performance - Outputs
Frequency Response: 20Hz - 20kHz +/- 0.2dB

THD+N : 105dB 'A-weighted' (all outputs)

Clock Jitter < 250 pico seconds

Sample Rate: 44.1 to 96kHz

Weight and Dimensions
1.1kg - 6.5cm x 17cm x 17cm
