FOS Quadro DSP 6.4,digital power amplifier,4x1500W@8Ω/4x2000W@4Ω

Proizvođač: FOS
Naziv: Quadro DSP 6.4,digital power amplifier,4x1500W@8Ω/4x2000W@4Ω
Šifra: FL006199 █ Model: L006199

╔════════════════════════
⇨ ZAŠTO ODABRATI OVAJ PROIZVOD ?
╚════════════════════════
DSP digital power amplifier, 4x1500W@8Ω / 4x2000W@4Ω ,Bridge 2x3200W@8Ω, Build-in DSP processor, D class, compressor, limiter, noise gate, PEQ, matrix mixer, delay, FIR function, support 4x2048 Taps, 4.3 IPS colorful capacitive touch display, Ethernet, USB, RS485, RS232, Support constant pressure and resistance: 100V, 70V, 8Ω, 4Ω.


✪ ✪ JAMSTVO 2 GODINE ✪ ✪ s R1 računom!

╔═════════════════════════
⇶ ISTAKNUTE KARAKTERISTIKE (original) :
╚═════════════════════════
Product Description:
Quadro 6.4, is a multi-functional network DSP digital power amplifier. It can monitor the status of amplifier and adjust the function of DSP in real time remotely. Built-in DSP functions with compressor, limiter, noise gate, PEQ, matrix mixer, delay etc. Mconsole software with its elegant interface provides with easy setup and nice operation experience. Variety of connection methods make it configurable and extensible. Suitable for various occasions in the PA project.

Suitable for: Performance & Art Centers, Theaters, Stadiums, Hotels, Meeting Rooms, Shopping Malls, Retail Stores, Restaurants.

Technical Specifications:
Power: 4*1500W@8Ω, 4*2000W@4Ω.
Bridged Power: 2*3200W@8Ω
Input Audio Source: Analog, Sine wave, Pink noise, White noise, AES
Input Volume: Mute, Phase, Level detector
Input EQ: 31 bands EQ
Input Noise Gate: Attack time 1～2895ms, Release time 1～2895ms, Threshold level -120dBu～0dBu.
DSP Matrix: 4*4 matrix zone
Output EQ: 10 bands EQ
Frequency Divider: Butterworth, Bessel, Linkwitz-Riley
Delay Input delay: 4×80ms Output delay: 4×20ms
Output Compressor: Soft knee, Threshold level, Attack time, Compression ratio, Releasing time
Output Limiter: Voltage 0.01V～89.50V, Power 0.01W～1000W, Release time 1~2895ms
Output Volume: Mute, Phase, Level detector
DSP Preset: 80 packages
Control Mode: Ethernet, USB, RS485, RS232
Network Model: TCP/IP、1000base-T/100base-TX、RJ45
Channels: 4
Minimum output impedance: Each channel 4Ω, bridged mode 8Ω
Input Interface: Balanced input 4×XLR
Output Interface: Spoken*4, XLR×4
Cooling System: Dual fans intelligent control
Gain: 6dB sensitivity: 30dB (×29.5); 0dB sensitivity: 36dB (×31.1)
Max input level: 20dB sensitivity: 20dBu (7.75V)
SNR: 12dB sensitivity: 94dB; 6dB sensitivity: 94dB; 0dB sensitivity: 94dB
Frequency Response: 20Hz～20kHz (±0.5dB)@1W, 8Ω
THD+N:
