EUROLITE DMX Split 8X Splitter

EUROLITE DMX Split 8X Splitter

MPC: 321,00€, cijena za gotovinu/virman -15%: 270,00€


Splitter with 8 galvanized isolated outputs, 3/5-pin & QuickDMX XLR sockets

DMX splitter for splitting one DMX input signal to 8 DMX outputs
Connections: 1 x DMX input, 1 x DMX feed-through output, 8 x DMX output
Additional QuickDMX input for wireless reception of DMX signals
Input and outputs XLR 3-pin and 5-pin each
Input and outputs galvanically isolated
Each DMX output with independent driver and status indicators
Input and outputs with a set of respective power supply and internal fuse
Switchable termination resistor
Rack mounting
Control: QuickDMX via 5-pin XLR (M) mounting version (optional)


TECHNICAL SPECIFICATIONS:

Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 5 W
Power connection: Mains input IEC connector (M) mounting version Power supply cord with safety plug (provided)
DMX input: 1 x 3-pin XLR (M) mounting version
1 x 5-pin XLR (M) mounting version
DMX output: 8 x 3-pin XLR (F) mounting version Separate (galvanic)
8 x 5-pin XLR (F) mounting version Separate (galvanic)
1 x 5-pin XLR (F) mounting version switchable bypass/terminating resistor
1 x 3-pin XLR (F) mounting version switchable bypass/terminating resistor
Control: QuickDMX via 5-pin XLR (M) mounting version (optional)
Width: 48.3 cm
Height: 4.45 cm
Depth: 14.5 cm
Weight: 2.22 kg
