Protek digital multi meter 506

Prodajem novi protek digital multi meter
Nov,nekoriste u originalnoj ambalazi


• Dual display for frequency,AC voltage and Temperature measurements
• 10 MHz frequency counter and decibel measurement.
• True RMS AC voltage and current readings
• RS-232 interface and software for downloading measurements to a
PC(model 506 only)
• 10 memory locations and analog bar graph
• Time and Stop watch mode with Alarm
• Min., Max., Avg and Relative mode
• Capacitance and Inductance measurement
• Temperature measurement in Centigrade and Fahrenheit
• Frequency generator, logic probe function and back light
• Auto power off and "keep on" modes
SPECIFICATIONS
DC Voltage Range 400mV 4V,40V,400V,1000V
Resolution 0.1mV 1mV,10mV,100mV,1V
Accuracy 0.3%+2d 0.5%+2d
AC Voltage Range 400mV 4V,40V,100V,750V
Resolution 0.1mV 1mV,10mV,100mV,1V
Accuracy 1%+3d 1.5%+5d
DC Current Range 400uA,400mA,20A
Resolution 0.1uA,0.1mA,0.01A
Accuracy 1%+2d
AC Current Range 400uA,400mA,20A
Resolution 0.1uA,0.1mA,0.01A
Accuracy 1.5%+3d
Resistance Range 400Ω,4KΩ,40KΩ
400KΩ 4MΩ,40MΩ
Resolution 0.1Ω,1Ω,10Ω,
100Ω 1KΩ,10KΩ
Accuracy 0.5%+2d 1%+2d
Frequency Range 10KHz,100KHz,1MHz,10MHz
Resolution 1Hz,10Hz,100Hz,1KHz
Accuracy 0.01%±2d
Capacitance Range 100uF
Resolution 0.01uF
Accuracy 3%+5d
Temperature Range -20°C-1200°C/0°F-2000°F
Resolution 1°C/°F=32+(9/5*°C)
Accuracy 3%+3d(10-350°C),5%+3d(350°C-1200°C)
dBm Range -25dBm-+59dBm
Resolution 0.01dBm
Accuracy ±0.5dBm
Logic Test Logic 0.8V-2.0V
Diode Test Test Volt 3.3V Max.
Continuity Less Than 100Ω
Signal Out 2048Hz,4096Hz,8192Hz(4.5 Square Wave)
Basic Accessories Carrying Case,Maual,Test Leads,Gift Box,
Battery,RS232C Cable
Optional Accessories Holster,Temp Probe (TP35,"K"Type),Temp
