LD Systems ZONE 624 4-zonski mikser

LD Systems ZONE 624 4-zonski mikser

MPC: 620,00€, cijena za gotovinu/virman: 520,00€


The ZONE 624 is a fully-equipped zone mixer with 6 line and 2 microphone channels, that can be assigned to a stereo or a mono master output. The compact 3U rack device also has inputs for an external emergency announcement system and remote- controlled switching mute. Due to its extensive connectivity the ZONE 624 is the extremely flexible control centre solution for PA systems in food outlets, clubs, hotels, fitness centres, and many other areas.

Specifications:

Product type: Mixers
Type: Installations
Number of Zones: 4 (Master, Zone A-C)
Type: stereo
Installation Height: 3 U
Total Input Channels: 8 (2x Mic, 1x AUX/Line, 2x Phono/Line, 2x Line, 1x FOH/Line
Frequency response: 20 - 40000 Hz
Microphone channels: 2 (with phantom power 12 V)
Microphone Channel Connections: 6.3 mm stereo jack (2 x balanced) , XLR
Microphone channel controls: 1 x EQ Hi , 1 x EQ Low , 1 x Talkover , 1x EQ Mid , 2 x gain , 2x On/Off
Microphone Channels Display Elements: On-LED
Microphone Channels Input Impedance: 4 kOhm
Microphone Channels Input Sensitivity: 4.5 mV
Microphone Channels THD: 0.08 %
Line Channels: 6 (Input 1: Aux/Line, Input 2 + 5: Line/Phono, Input 3: USB/Line 4: Line, Input 6: Line/FOH
Line input connectors: input 2, 4, 5: 2 x RCA, Input 1: 2 x RCA + 3.5 mm stereo jack, input 3: 2 x RCA + USB, input 6: 4 x RCA + 2 x 6.3 mm jack
Line Channel Controls: 2x Phono/Line, AUX enable, Cue , FOH On, Gain, level
Line Channel Display Elements: Cue-LED, Signal/0 dB-LED
Line Channel Input Impedance: (Phono) 50 kOhm, 6 kOhm
Line Channels Input Sensitivity: (Phono) 25m V, 2.1 V
Line Channels THD: (Phono) 0.05% , 0.02%
input sensitivity AUX/Line: 3 V
Line outputs: 5 (Master - Stereo, 3x Zone - Mono, Rec - Stereo)
Output Connectors: Master 2 x XLR (balanced), RCA (x2), terminal block
Master Controls: EQ Hi, EQ Low, EQ Mid, level, Max. Level, T/O Damping, T/O Sensitivity
Master Display Elements: 2 x 10 segment level meter
Master Output Levels: (balanced) 24 dBu, (unbalanced) 17 dBu
Zone Output Connections: terminal block , XLR (balanced)
Zone Controls: 100 Hz High Pass, Cue, EQ Hi, EQ Low, Include Mic, level, Max. Level, Source, T/O Damp
Zone Display Elements: 5-Segment Level Meter
Zone Output Levels: 24 (balanced/ unbalanced) dBu
Output Connections: Rec 2 x RCA
Headphones ouput: 1
Headphone Out Port: 6.3 mm TRS
Headphone Output Controls: Cue Volume
Headphone Output Voltage (@ 32 Ohm): 2.5 V
Additional Inputs: 2 (Emergency Input, Output Mute)
Connections Additional Inputs: terminal block
Additional Input Controls: Level Emergency Input
Input Sensitivity Emergency Input: 5 V
Additional Controls: power switch
Additional Display Elements: Power-LED
Operating voltage: 220 - 250 V AC, 50 Hz
Mains connector: IEC power connector
Power consumption: 25 W
Fuse: T 500 mAL / 250 V
Width: 485 mm
Height: 132 mm
Depth: 210 mm
Weight: 4,4 kg
Accessories (included): Power cord, terminal blocks
