Audio mikser/mikseta MACKIE ONYX 3280 32 kanala

Audio mikser/mikseta MACKIE ONYX 3280, 32 mono kanala, 8 stereo kanala, 8 auxa, 8 grupa, 4 mute grupe, u originalnoj ambalaži.

Kontakt broj: 099 272 0222 - Ivan.

ONYX3280

Channel strip features:
Premium Onyx microphone preamps on every channel
4-band Perkins EQ with hardware bypass
48V phantom power, mic/line, 100hz high-pass, and polarity switches
8 auxiliary sends with Pre/Post switches
Aux. stereo link feature for IEM applications
Direct outputs on DB-25 connectors (8 channels per connector)
4 segment LED level indicators
Smooth, long-throw 100mm faders
Mute, and PFL Solo switches
Balanced XLR mic and 1/4" line inputs, plus 1/4" insert jack
Perkins EQ - the "British" sound improved
The goal for the Onyx 3280 was no short order: a large format analog mixer with more useful features, better sound quality and advanced tonal shaping. To accomplish this Mackie employed their new Perkins EQ circuitry, a "neo classic" 4-band design which gives you the sweet musicality of British EQ with greater filter control and minimum phase shift (plus a true hardware EQ bypass).

The Onyx 3280 matches Mackie’s small format consoles in the "built like a tank" category. It’s built for the road, with heavy-duty cabinet and components that can take it. The 100mm Alps channel faders will hold up to thousands of gigs, and the easy-to-read console delivers famous Mackie simplicity. The Onyx 3280 mixer will be your best buddy on the road!

Mackie Onyx 3280 Mixing Console Features:
Premium analog 8-bus sound reinforcement console
32 great-sounding, low-noise, high-headroom Onyx mic preamps
4-band Perkins EQ with high/low shelving and dual sweepable mids on every channel
Smooth, accurate 100mm Alps faders on channels and groups
8 pre/post-switchable, stereo-linkable aux sends - great for in-ear monitor mixes
8 stereo aux return channels with 4-band Perkins EQ, 60mm fader and flexible routing
Two large 12-segment stereo meters dedicated to main output and solo levels
4-segment metering on all channels, groups and aux returns
On-board talkback functionality with extensive routing capability

Built-in "Real World" power supply 100-240 volts, 50-60Hz, 105W

SPECIFICATIONS:
Analog Inputs- 32 XLR, 32 TRS
Analog Outputs- 8 TRS
Automation- N/A
Aux Returns- 8
Aux Sends- 8
Busses- 8
D/A Res- N/A
Direct Outs- 32
EQ Bands- 4 param. w/ high/low shelving
EQ Type- Parametric
Expansion- N/A
Faders- 32 100mm
Freq. Response- 20Hz - 20kHz
Inserts- 32
Internal Res.- N/A
Phantom Power- 48-volt
Power Supply- 120-240 volt
Rack Height- N/A
Total Channels- 32

Za sve informacije isključivo zvati na broj 099 2720222 jer je ovo oglas iz usluge.
