Xeon X3360 + Asus P5E64 WS Evolution + Asus Silent Square EVO

Asus P5E64 WS EVOLUTION MBO

Supported CPU
CPU Socket Type
LGA 775
CPU Type
Core 2 Quad / Core 2 Extreme / Core 2 Duo
FSB
1600/1333 MHz

Chipsets
Chipset
Intel X48
South Bridge
Intel ICH9R

Memory
Number of Memory Slots
4×240pin
Memory Standard
DDR3 1800(O.C.) / 1600 (O.C.) / 1333
Maximum Memory Supported
8GB
Channel Supported
Dual Channel

Expansion Slots
PCI Express 2.0 x16
4 x PCIe x16 (@ x16, x16, x4, x4)
PCI Express x16
4
PCI Express x4
1 x PCI Express x4
PCI Slots
2 x PCI Slots

Storage Devices
PATA
1 x ATA100 2 Dev. Max
SATA 3Gb/s
8 x SATA 3Gb/s
SATA RAID
0/1/5/10

Onboard Audio
Audio Chipset
ADI AD1988B
Audio Channels
8 Channels

Onboard LAN
LAN Chipset
Marvell 88E8056
Second LAN Chipset
Marvell 88E8001
Max LAN Speed
Dual 10/100/1000Mbps

Rear Panel Ports
PS/2
1
USB 1.1/2.0
6 x USB 2.0
IEEE 1394
1 x IEEE 1394a
eSATA
2 x eSATA 3Gb/s
S/PDIF Out
1 x Optical, 1 x Coaxial
Audio Ports
6 Ports

Internal I/O Connectors
Onboard USB
6 x USB 2.0
Onboard 1394
1 x 1394a

Samo ploca s IO limicem i diagnostickom karticom.

https://www.asus.com/Motherboards/P5E64_WS_Evolution/


Asus Silent Square EVO hladnjak s ventilatorom

https://www.asus.com/Thermal-Solution/Silent_Square_EVO/


Intel Xeon X3360 2.83 GHz 12M L2 socket 775 (Core 2 Quad 9550 ekvivalent)

http://ark.intel.com/products/33933/Intel-Xeon-Processor-X3360-12M-Cache-2_83-GHz-1333-MHz-FSB


+ opcionalno DDR3 memorija


Saljem postom ili Overseasom

Mail za kontakt: transonic.njuskalo@gmail.com






lga 775 lga775 c2q cooler maticna ploca
