Prodajem samo maticnu (bez procesora i memorije). Imam kutiju, manual, CD sa driverima i sve sto dolazi u paketu.
Processor
Socket 478 Intel® Pentium® 4
Chipset
SiS655 HMAC Host & Memory & AGP Controller
SiS963 MuTIOL® Media I/O
Super I/O: ITE IT8705F
ITE GigaRAID controller
Silicon Image sil3112A controller
Realtek 8101L LAN controller
Realtek ALC650E AC'97 Codec
Front Side Bus
533 / 400 MHz FSB
Memory
DDR 400 (PC3200)* / DDR 333 (PC2700) / DDR 266 (PC2100) 184pin
4 x DIMM slots up to 4GB
Internal I/O Connectors
1 x CD / AUX in
1 x FDD
1 x IEEE 1394 pin header (support 3 ports by daughter card S1394)
1 x SPDIF in/out
1 x WOL header
2 x SATA
2 x USB 2.0/1.1 (supports 4 ports)
3 x cooling fan pin headers
4 x UDMA ATA 133/100/66 Bus Master IDE
Expansion Slots
1 x AGP slot (8x/4x-AGP 3.0 compliant), supports 1.5v display card only
5 x PCI slots (PCI 2.2 compliant)
Rear Panel I/O
1 x Game / Midi
1 x LPT
1 x RJ45 LAN
2 x COM
2 x USB 2.0/1.1
3 x Audio jacks (Line-in/Line-out/MIC)
PS/2 (Keyboard/Mouse)
CPU/AGP/DIMM setting
AGP Clock adjustable via BIOS
AGP Voltage adjustable via BIOS
CPU FSB / Multiplier / Vcore Voltage adjustable via BIOS
DIMM Voltage / Clock adjustable via BIOS
Form Factor
ATX, 4 layers PCB, 305mm x 244mm
H/W Monitoring
Hardware detecting and reporting for case open, power-in voltage, CPU voltage and fan speed
System health status auto-detect and report by BIOS
BIOS
2 x 2 Mbit flash ROM
2 x 2M bit flash ROM, enhanced ACPI feature for PC98/Win98/Win2000/Me/CE/XP compliance, Green, PnP, DMI, INT13 (>8.4GB) and Anti-Virus functions
IDE#1~#2, SCSI, LS120, ZIP and CD-ROM bootable
Bundle Software
Ad Control
Driver
ITE IDE RAID driver
Realtek audio driver
Realtek LAN driver
Silcon Image Serial ATA driver
SiS 655 AGP driver
Other Features
@BIOS™, EasyTune™ 4, Q-Flash™, GMC™
Poly fuse for keyboard overcurrent protection
STR (Suspend-To-RAM)
USB Keyboard or mouse wake up from S3
Detalji na
http://ee.giga-byte.com/products/mb/specs/ga-8sq800_ultra.html
