Magnum Dynalab MD 109 FM Tuner
- Cijena
- 5.300 €
Šifra oglasa: 38215467
Osnovne informacije
- Lokacija
- Grad Zagreb, Trnje, Vrbik
- Stanje
- rabljeno
Opis oglasa
Magnum Dynalab MD 109 FM Tuner
Specifications:
Usable sensitivity (mono) 0.7 u V 9.0 dBf 50 dB quieting (mono) 2.0 u V 9.9 dBf 50 dB quieting (stereo) 2.3 u V 20.0 dBf Capture ratio 1.5 dB Image rejection 125.0 dB Alternate channel (wide) >46.0 dB Alternate channel (narrow) >70.0 dB Alternate channel attenuation (super narrow) 80.0 dB Adjacent channel (wide) 3.0 dB Adjacent channel (narrow) 21.0 dB Adjacent channel (super narrow) 48.0 dB THD (mono) 0.10% THD (stereo) 0.10% Stereo separation 50.0 dB AM suppression 70.0 dB SCA rejection 80.0 dB IF Rejection 80.0 dB 19 KHz & 38 KHz component rejection 75.0 dB Audio frequency response 2 Hz to 200 Khz (+0,-0.1 dB)
Balanced audio output (600 ohms) 3.0 V
Line audio output (RCA) 1.5 V
Output impedance 200 ohms (2 Hz - 200 KHz)
Signal to noise ratio > 110 dB
Fuse replacement, 115 volts 1 amp Fuse replacement, 230/240 volts 0.5 amp
Tube replacement (position 1&2) MD Reference 6922 CryoValve .
Tube replacement (position 3&4) MD Reference 6922
Line power (must be specified) - 110/220/230/240 VAC
Dimensions (H.W.D.) : 15.24 x 48.3 x 40.7 cm
Weight :17.1 kg.
Power consumption (Typ/Max) : 50w / 100w.
Specifications:
Usable sensitivity (mono) 0.7 u V 9.0 dBf 50 dB quieting (mono) 2.0 u V 9.9 dBf 50 dB quieting (stereo) 2.3 u V 20.0 dBf Capture ratio 1.5 dB Image rejection 125.0 dB Alternate channel (wide) >46.0 dB Alternate channel (narrow) >70.0 dB Alternate channel attenuation (super narrow) 80.0 dB Adjacent channel (wide) 3.0 dB Adjacent channel (narrow) 21.0 dB Adjacent channel (super narrow) 48.0 dB THD (mono) 0.10% THD (stereo) 0.10% Stereo separation 50.0 dB AM suppression 70.0 dB SCA rejection 80.0 dB IF Rejection 80.0 dB 19 KHz & 38 KHz component rejection 75.0 dB Audio frequency response 2 Hz to 200 Khz (+0,-0.1 dB)
Balanced audio output (600 ohms) 3.0 V
Line audio output (RCA) 1.5 V
Output impedance 200 ohms (2 Hz - 200 KHz)
Signal to noise ratio > 110 dB
Fuse replacement, 115 volts 1 amp Fuse replacement, 230/240 volts 0.5 amp
Tube replacement (position 1&2) MD Reference 6922 CryoValve .
Tube replacement (position 3&4) MD Reference 6922
Line power (must be specified) - 110/220/230/240 VAC
Dimensions (H.W.D.) : 15.24 x 48.3 x 40.7 cm
Weight :17.1 kg.
Power consumption (Typ/Max) : 50w / 100w.
