Metronome Technologie AQWO 2

Specification:

CONVERSION PROCESSORS
Reference
• ES9039MPRO
Range
• High-End
THD+N
• -122 d
Dynamic range
• S/N 137 dB

ANALOG OUTPUTS
RCA
• Output impedance: 100 Ohms
• Max. output level (0dB): 3Va
XLR
• Output impedance: 150 Ohms
• Max. output level (0dB): 3V
DIGITAL OUTPUTS
(resampling available)
S/P DIF
• PCM: 44.1 to 384 kHz / 32 bits
• DSD: DSD64 to DSD128 DoP
AES/EBU
• PCM: 44.1 to 384 kHz / 32 bits
• DSD: DSD64 to DSD128 DoP
I2S
• PCM: 44.1 to 384 kHz / 32 bits
• DSD: DSD64 to DSD256 Native
OPTIONS
Tube outputs
DIGITAL INPUTS
S/P DIF
• PCM: 44.1 to 384 kHz / 32 bits
• DSD: DSD64 to DSD128 DoP
AES/EBU
• PCM: 44.1 to 384 kHz / 32 bits
• DSD: DSD64 to DSD128 DoP
Toslink
• PCM: 44.1 to 192 kHz / 32 bits
• DSD: DSD64 DoP
USB
• PCM: 44.1 to 384 kHz / 32 bits
• DSD: DSD64 to DSD512 Native
Streaming
• PCM: 44.1 to 384 kHz / 32 bits
• DSD: DSD64 to DSD256 Native
NETWORK
Wi-Fi
• Dual Band (2,4 & 5 GHz)
Ethernet
• 1 x Port Ethernet 10 / 100 / 1000
MQA
• Renderer MQA 44.1 to 384 kHz / 32 bits
Supports of protocole
• DLNA/UPnP, Audirvāna, Spotify Connect, Roon Ready,
Deezer, TIDAL Connect, Qobuz Connect, vTunner
GENERAL SPECIFICATIONS
Power consumption
• 40 Watts
Standby power consumption
• 32 Watts
Operating temperature
• +5°C to +35°C
Operating humidity
• 5% to 90%
USB
• 1 x Port USB 2.0 (for device update)
Dimensions (L x H x W)
• 420 x 120 x 425 mm (drive)
Weight
• 15 kg (drive)
DISPLAY
Size
• 7 inches

Resolution
• 1024 x 600

Touch screen
• Yes
