Visokonaposnki izvor napajanja DC 50kv 5mA
- Cijena
- 100 €
Šifra oglasa: 36347805
Osnovne informacije
- Lokacija
- Varaždinska, Varaždin, Biškupec
- Stanje
- rabljeno
- Razgledavanje putem video poziva
- Da
Opis oglasa
Hipotronics 50B, testirano, ispravno
Moguća zamijena za razno
Model Number: PP50-5 (Prev. 50B)
Specifications: 50 kV, 5 mA DC
Features:
Compact Size
Metal Can Construction
Surge Limited Resistors in output
Continuous Duty Rated at maximum rating
115 or 220 V 50/60 Hz selectable input
Bleed Resistors Built into output
Oil Insulated in a hermetically sealed unit
Reversible polarity
Benefits:
Compact - saves valuable space
Rugged Design - suited for use in harsh environments
Built in Bleeder Resistors - doesn't hold charge when power is turned off
Hermetically Sealed - Moisture can't enter high voltage tank
Applications:
X-Ray Systems
Laser Systems
Precipitators
Medical Equipment
General Purpose HV Source
Brief Description:
Hipotronics DC Power Packs are complete high voltage sections designed for OEM use or any application requiring high voltage test equipment at low current levels.
Specifications:
Input Voltage: 115 V @ 3 A, 220 V @ 1.6 A
Output Voltage: 20 kV
Output Current: 5 mA
Regulation: Less than 15%
Ripple: 0.5% per mA of output current
Insulation: Oil
Internal Shorting: Bleed Resistors
Polarity: Reversible
Dimensions: 11.5" H x 6" W x 6" D (295 mm H x 153 mm W x 153 mm D)
Weight: 30 lb. (13.6 kg)
Moguća zamijena za razno
Model Number: PP50-5 (Prev. 50B)
Specifications: 50 kV, 5 mA DC
Features:
Compact Size
Metal Can Construction
Surge Limited Resistors in output
Continuous Duty Rated at maximum rating
115 or 220 V 50/60 Hz selectable input
Bleed Resistors Built into output
Oil Insulated in a hermetically sealed unit
Reversible polarity
Benefits:
Compact - saves valuable space
Rugged Design - suited for use in harsh environments
Built in Bleeder Resistors - doesn't hold charge when power is turned off
Hermetically Sealed - Moisture can't enter high voltage tank
Applications:
X-Ray Systems
Laser Systems
Precipitators
Medical Equipment
General Purpose HV Source
Brief Description:
Hipotronics DC Power Packs are complete high voltage sections designed for OEM use or any application requiring high voltage test equipment at low current levels.
Specifications:
Input Voltage: 115 V @ 3 A, 220 V @ 1.6 A
Output Voltage: 20 kV
Output Current: 5 mA
Regulation: Less than 15%
Ripple: 0.5% per mA of output current
Insulation: Oil
Internal Shorting: Bleed Resistors
Polarity: Reversible
Dimensions: 11.5" H x 6" W x 6" D (295 mm H x 153 mm W x 153 mm D)
Weight: 30 lb. (13.6 kg)
