PRETVARAČ NAPONA-POWER INVERTER 1500W -12V NA 220V LED ZASLON

RAČUN+GARANCIJA 1 GODINA
UZ PRETVARAČ DOLAZI AUTO UTIČNICA TAKO DA GA JE MOGUĆE KORISTITI U AUTOMOBILU!
MOGUĆNOST POVRATA UREĐAJA TE POVRATA NOVCA AKO UREĐAJ NE ODGOVARA (UREĐAJ JE MOGUĆE VRATITI U ROKU OD 14 DANA NAKON PREUZIMANJA)
Pogodno za vikendice, vozila, kamp kućice, brodove, čamce, šatore i sl.
Mogućnost povezivanja sa regulatorima punjenja i solarnim pločama.
Pretvarač napona 12v na 220v sa LED zaslonom koji pokazuje ulazni i izlazni napon sa USB portom re razinu napunjenosti akumulatora/baterije
Na pretvaraču postoje dva USB porta. Uz pretvarač dolaze dvije štipaljke i konektor za auto upaljač.
Vršna snaga: 1500W
Nazivna snaga: 850W
Ulazni napon: 12V
Izlazni napon AC 220V / 50Hz
USB izlaz: 5V-2A
Struja bez opterećenja: 0,9A
Digitalni zaslon: LCD / ulazni / izlazni napon
Valni oblik izlaznog napona: Modificirani sinusni val
Učinkovitost pretvorbe: 90%

Opis:
Modul: EASUN KML 1500 W
Crna boja
Materijal: Aluminijska legura
Stil utičnice: Univerzalna EU utičnica
Ugrađeni ventilator za hlađenje s niskom razinom buke.
Dostupno sučelje za punjenje putem USB izlaza.
Pozitivni i negativni polni terminal
Radna lampica
Ručni prekidač pretvarača
Veličina: 210mm*110mm*60mm

Značajke:
Siguran raspon ulaznog napona:
12V idealno ili 9,8-15V
Pretvarač može pretvoriti DC 12 V u izmjenični 220V.
Raspoloživi raspon nazivnog napona električnih uređaja: 210-230V


Postoji 8 funkcija sigurnosne zaštite:

Zaštita od obrnutog polariteta
Zaštita od niskog ulaznog napona
Zaštita od visokog ulaznog napona
Zaštita od prekomjerne struje
Zaštita od kratkog spoja
Zaštita od prekomjerne temperature
Zaštita od preopterećenja
Postoji unutarnji osigurač koji će sigurno prekinuti strujni krug ukoliko dođe do preopterećenja

Primjena:
Primjenjiva opterećenja za nazivnu snagu do 950 W:

Paket uključuje:
1 x solarni pretvarač
1 x kopča za akumulator
1 x kabel za priključan na upaljač u automobilu
1 x korisničke upute

Model: EASUN KML-1500W-12V-220V-EU
Peak Output Power 1500W
Continues Output Power 950W
30-minute Output Power 750W
Output Waveform:: Modified sine wave
Frequency 50HZ±2HZ
No load current draw 90%
input DC Voltage 12V
DC Voltage Range 9V-15.5V
output AC Voltage 220V
AC Voltage Range 210V-240V
Low Voltage Alarm 10V DC±0.5V
Low Voltage:Shut Down 9V DC±0.5V
Over Load: Shut Off Output
Over Voltage: Shut Down 15.5V
Over Thermal: Shut Off Output Automatically
Fuses: Short Circuit
Start: Soft Start
ProtectioN Overload, Short Circuit, Overtemp, Reverse Polarity, Under/Over Voltage
Cooling Fans
Production Condition: Brand New
Warranty: 1 Year
Machine Size(mm) 210mm*110mm*60mm
Net Weight(kgs) 0.9kgs
USB Double USB 3.1A

Features:

1. Aluminum-magnesium alloy casing, light weight, good thermal conductivity, can quickly reduce the temperature of parts, long-term work is not affected
2. Using S TM chip technology, high reliability, strong shock resistance, low solder joint defect rate, reducing battery and radio frequency interference
3. Eight intelligent protection, overload protection, high voltage protection, low voltage protection, over temperature protection, reverse polarity protection, short circuit protection, over current protection, insurance protection
4.Modified sine wave, intelligent filter, no interference to electrical appliances, protection of electrical appliances
5, up to 93% conversion rate, 30% conversion loss, 30% continuous power
6, intelligent temperature control fan, make the inverter quieter. When the temperature is ≤ 45 °C, the fan stops working; when the temperature is ≥ 45 °C, the fan starts to work.
7. Buzzer reminder device. Once any protection of the inverter is triggered, the inverter will immediately disconnect the power supply, the load enters the protection mode and reminds people via a buzzer reminder
8. Screw terminal. Pluggable plug for easy cable replacement
9, dual cooling fan to extend the life of the inverter
10. Universal three-hole socket, compatible, suitable for most electrical appliances
11. Low standby power consumption and high conversion rate
12, smart chip control

Essential details
Place of Origin:
Brand Name:
EASUN POWER
Model Number:
KML-1500W-12V-220V
Input Voltage:
12V/24V
Output Voltage:
220V
Output Current:
Ah
Output Frequency:
50 Hz
Output Type:
Single
Size:
320*150*90mm
Type:
DC/AC Inverters, Solar inverter
Inverter Efficiency:
92%
Weight:
1.2KG
Output voltage waveform:
Modified sine wave
Peak power:
1500W
Continuous power:
850W
Output voltage:
220v
Input voltage:
12v / 24v
Output frequency:
50Hz
Low-voltage protection:
9.5v / 20v
High-pressure protection:
16v / 30v
Conversion rate:
93% or more
